BP565 UHF

Digital DMR UHF 5W 64CH

О товаре

General data
Frequency Range UHF：400~470 MHz
Channel Capacity 256
Zone Capacity 8
Channel Spacing 12.5 kHz/20 kHz/25 kHz
Operating Voltage 7.4 V (rated)
Battery standard:1500 mAh 7.4 V ;Optional:2200 mAh 7.4 V
Battey Life(5/5/90 Duty Cycle,High TX Power) 12 h (1500 mAh); 16 h (2200 mAh)
Frequency Stability ±0.5 ppm
Antenna Impedance 50 Ω
Dimensions(H×W×D) mm 115 mm x 55 mm x 29.5 mm
Weight 230 g
Display 1.77 inch TFT
BT BT 5.0 BLE+EDR
Receiver
Sensitivity(Analog) 0.18 μV (12 dB SINAD)
Sensitivity(Digital) 0.18 μV/BER5%
Adjacent Channel Selectivity TIA-603: 60 dB@12.5 kHz / 70 dB@20/25 kHz ETSI: 60 dB@12.5 kHz / 70 dB@20/25 kHz
Intermodulation TIA-603: 70 dB@12.5/20/25 kHz; ETSI: 65 dB@12.5/20/25 kHz
Spurious Response Rejection TIA-603: 70 dB@12.5/20/25 kHz; ETSI: 70 dB@12.5/20/25 kHz
Blocking TIA-603: 80 dB; ETSI: 84 dB
Hum&Noise 40 dB@12.5 kHz; 43 dB@20 kHz; 45 dB@25 kHz
Rated Audio Power Output 1 W
Rated Audio Distortion ≤3%
Audio Response +1~-3 dB
Transmitter
RF Power Output UHF：4 W/1 W; VHF：5 W/1 W
FM Modulation 11K0F3E@12.5 kHz; 14K0F3E@20 kHz; 16K0F3E@25 kHz
4FSK Digital Modulation 12.5 kHz data only: 7K60FXD; 12.5 kHz data and voice: 7K60FXW
Conducted/Radiated Emission -36 dBm＜1 GHz; -30 dBm＞1 GHz
Modulation Limiting ±2.5 kHz@12.5 kHz; ±4.0 kHz@20 kHz; ±5.0 kHz@25 kHz
FM Hum&Noise 40 dB@12.5 kHz; 43 dB@20 kHz; 45 dB@25 kHz
Adjacent Channel Power 60 dB@12.5 kHz; 70 dB@20/25 kHz
Audio Distortion ≤3%
Environmental Specs
Operating Temperature -30 ℃ to +60 ℃（Radio only - Battery -20 ℃）
Storage Temperature -40 ℃ to +85 ℃
ESD IEC 61000-4-2 (Level 4) ±8 kV (contact); ±15 kV (air)
MIL Standard MIL-STD-810 G
Dust & Water Protection IP54
Humidity MIL-STD-810 G
