US-XG-6POE
332 000 AMD
A Layer 3, PoE switch with (4) 10 GbE, PoE++ RJ45 ports and (2) 10G SFP+ ports.
US-XG-6POE | |
---|---|
Dimensions | 165 x 268.1 x 31.8 mm |
Weight | 1.3 kg |
Networking Interfaces | (4) 100/1000 Mbps and 2.5/5/10G RJ45 Ports (2) 1/10G SFP+ Ethernet Ports |
Management Interfaces | Ethernet In-Band (1) RJ45 Serial Port Out-of-Band (1) USB Type C Port Out-of-Band |
Power Method | 54VDC, 3.88A Power Adapter (Included) or DC Input with Terminal Block |
Power Supply | External AC/DC Adapter (Included) or DC Power Source |
Supported Voltage Range | 44 to 57VDC |
Max. Power Consumption (Excluding PoE Output) |
40W |
LEDs System RJ45 Data Ports SFP+ Data Ports |
Status PoE; Speed/Link/Activity Link/Activity |
ESD/EMP Protection | Air: ± 18 kV, Contact: ± 12 kV |
Shock and Vibration | ETSI300-019-1.4 Standard |
Operating Temperature | -5 to 45C |
Operating Humidity | 5 to 95% Noncondensing |
Certifications | CE, FCC, IC |
POE | |
PoE Interfaces | PoE++ IEEE 802.3bt (Pair A 1, 2+; 3, 6-) (Pair B 4 , 5+; 7, 😎 |
Max. 802.3bt Wattage per Port by PSE | 60W |
Voltage Range 802.3af Mode | 44-57V |
Voltage Range 802.3at/bt Mode | 50-57V |
