L41G-2axD&FG621-EA

hAP ax lite LTE6 kit with 800MHz CPU, 256MB RAM, 4 x Gbit LAN, 2.4GHz 802.11b/g/n/ax two chain wireless with integrated antenna, LTE CAT6 modem for International bands 1/3/5/7/8/20/28/38/40/41 with integrated antenna, tower case, PSU, RouterOS L4, International version

hAP ax lite LTE6

О товаре

Specifications

Details
Product code L41G-2axD&FG621-EA
Architecture ARM
CPU IPQ-5010
CPU core count 2
CPU nominal frequency 800 MHz
Switch chip model MT7531BE
RouterOS license 4
Operating System RouterOS v7
Size of RAM 256 MB
Storage size 128 MB
Storage type NAND
MTBF Approximately 100'000 hours at 25C

Wireless capabilities

Details
Wireless 2.4 GHz Max data rate 574 Mbit/s
Wireless 2.4 GHz number of chains 2
Wireless 2.4 GHz standards 802.11b/g/n/ax
Antenna gain dBi for 2.4 GHz 4.3
Wireless 2.4 GHz chip model IPQ-5010
Wireless 2.4 GHz generation Wi-Fi 6
WiFi speed AX600

Mobile

Details
3G Category R8 (42.2Mbps Downlink, 11.2Mbps Uplink)
3G bands 1 (2100MHz) / 3 (1800MHz) / 5 (850MHz) / 8 (900MHz)
LTE Category 6 (300Mbit/s Downlink, 50Mbit/s Uplink)
LTE FDD bands 1 (2100MHz) / 3 (1800MHz) / 5 (850MHz) / 7 (2600MHz) / 8 (900 MHz) / 20 (800MHz) / 28 (700MHz)
LTE TDD bands 38 (2600MHz) / 40 (2300MHz) / 41 (2500MHz)
TAC 86335904

Ethernet

Details
10/100/1000 Ethernet ports 4

Peripherals

Details
Number of SIM slots 1 Modem (Micro SIM)

Powering

Details
Number of DC inputs 1 (USB-C)
Supported Voltage 5 V
Max power consumption 12 W
Max power consumption without attachments 12 W
Cooling type Passive

Certification & Approvals

Details
Certification CE, EAC, ROHS
IP 20

Other

Details
Mode button Yes
