VS4524AU

28 500 dram

0 dram

MPPT Solar charge controller 45A 24V

В наличии

Type: MPPT (Maximum Power Point Tracking)
System Voltage: 12V / 24V Auto-Sensing
Max PV Input Voltage: 100V
Max PV Input Power: 520W (12V) / 1040W (24V)
Max Charging Current: 45A
Max Load Current: 20A (DC Output)
MPPT Tracking Efficiency: ≥ 99%
Conversion Efficiency: Up to 98%
Supported Battery Types: Sealed Lead-Acid (SLA), Gel, Flooded (Wet), Lithium (LiFePO4 – Selectable)
Battery Voltage Range: 9V – 32V
Temperature Compensation: -3mV/°C/cell (Configurable)
Communication: RS485 Port (MODBUS protocol)
Environmental: -25°C to +55°C operating temperature, IP32 enclosure rating
Dimensions: 200mm × 140mm × 60mm
Weight: 1.5kg
Certifications: CE, RoHS, IEC 62109, EN 61000
