IPC568E-G

Bullet, 12MP, Pro Model IPC568E-G Camera Sensor 1/1.7" progressive scan ,CMOS Lens Mount CS Shutter Auto/Manual, 1/6~1/100000 s Minimum Illumination Colour: 0.06 Lux (F1.2, AGC ON) B/W:0.03 Lux(F1.2, AGC ON) Iris DC-Iris 4V (4-Pin)/P-Iris 5V (4-Pin) Day & night Automatically removable IR-cut filter(ICR) Digital noise reduction 2D/3D DNR Motor Zoom/focus DC 5V (4-Pin) S/N >55dB Defog Optical Defog & Digital Defog WDR DWDR Video Video Compression Ultra 265,H.265, H.264, MJPEG H.264 code profile Baseline profile, Main Profile, High Profile Frame Rate Main Stream:12 MP(4000×3000):Max.20 fps，8MP(3840 × 2160): Max.25fps, 2MP(1920×1080)@30fps； Sub Stream:2MP(1920×1080) : Max. 30fps； Third Stream: D1 (720×576): Max. 30fps 9:16 Corridor Mode Supported HLC Supported BLC Supported ROI Up to 8 areas OSD Up to 8 OSDs Privacy Mask Up to 8 areas Motion Detection Up to 4 areas Smart Behavior Detection Intrusion, cross line, motion detection Exception Detection Audio detection Intelligent Identification Face detection, Defocus, Scene Change Statistical Analysis People counting General Function Watermark, IP Address Filtering, Tampering Alarm, Alarm input, Alarm output, Access Policy, ARP Protection, RTSP Authentication, User Authentication Audio Audio Compression G.711 Two-way audio Supported Suppression Supported Sampling Rate 8 KHZ Storage Edge Storage Micro SD, up to 128 GB Network Storage ANR Network Protocols IPv4, IGMP, ICMP, ARP, TCP, UDP, DHCP, PPPoE, RTP, RTSP, RTCP, DNS, DDNS, NTP, FTP, UPnP, HTTP, HTTPS, SMTP, 802.1x，SNMP Compatible Integration ONVIF(Profile S, Profile G), API Interface Audio I/O 3.5 mm audio interface 1 Input: impedance 35 kΩ; amplitude 2 V [p-p] 1 Output: impedance 600 Ω; amplitude 2 V [p-p] Alarm I/O 2 / 1 Serial Port 1 RS485 (support Pelco-D/P) Network 100M/1000M Base-FX SFP + 100M/1000M Base-TX Ethernet Video Output 1 BNC, impedance 75 Ω; amplitude 1 V [p-p] General Power 24 V AC±25%, 12 V DC±25%, PoE (IEEE802.3 af) Power consumption: Max 9.5W Dimensions (L × W × H) 151.5 x 71 x 65 mm (6.0“ x 2.8“ x 2.6”) (excluding the lens) Weight 0.48 kg (1.1 lb) Working Environment –20°C ~ 60°C (-4°F ~ 140°F), Humidity :10%~95% RH(non-condensing) Reset Button Supported
